Variants of Scout

Dronetag Scout is available in several configurations tailored to your monitoring needs.
Each setup combines omnidirectional and directional antennas to achieve the ideal coverage pattern for your environment.

Scout Antenna Options​

Dronetag Scout is available in multiple antenna configurations, allowing you to tailor the system to your specific monitoring needs.
Depending on your deployment — whether you need 360° situational awareness or extended range in one or more directions — you can choose from several combinations of omnidirectional and directional antennas for optimal airspace coverage.

2× Omnidirectional Antenna (Baseline)

The Baseline model includes two omnidirectional antennas providing full 360° airspace coverage.

  • One antenna operates at 2.4 GHz, the other at 2.4 GHz + 5 GHz.
  • This configuration is fully sufficient for general airspace awareness and locations with clear line of sight — ideal when mounted on elevated or unobstructed positions.
  • Provides balanced detection performance for most deployments.
2× Omnidirectional Antenna + 1× Directional Antenna

This configuration combines 360° coverage with extended range in one specific 90° direction.

  • Two omnidirectional antennas (2.4 GHz and 5 GHz) ensure full-area visibility.
  • One additional directional antenna extends detection range in a 90° sector at 2.4 GHz.
  • Perfect for installations where enhanced visibility is needed toward a single corridor or restricted zone.
2× Omnidirectional Antenna + 2× Directional Antenna

Enhanced setup for dual-sector coverage.

  • Omnidirectional antennas maintain 360° baseline visibility.
  • Two directional antennas extend detection range in two 90° sectors (each at 2.4 GHz).
  • When aligned adjacently, the improved coverage area reaches up to 180°.
  • Ideal for wide facility perimeters or dual-zone observation.
2× Omnidirectional Antenna + 3× Directional Antenna

Advanced version offering extended range in three directions.

  • Full omnidirectional baseline (2.4 GHz + 5 GHz).
  • Three directional antennas enhance range in three 90° sectors at 2.4 GHz.
  • When arranged in sequence, they can provide up to 270° of boosted coverage.
  • Recommended for installations requiring focused long-range detection on multiple approach paths.
1× Omnidirectional Antenna + 4× Directional Antenna

Ultimate 360° detection configuration.

  • Four directional antennas provide full extended-range coverage (360°) on 2.4 GHz.
  • One omnidirectional antenna ensures complete 5 GHz visibility in all directions and also serves as a backup receiver for 2.4 GHz in case any directional antenna becomes jammed or experiences interference.
  • Designed for critical infrastructure, airports, or urban rooftops where maximum range and reliability are essential.

Optional Add-Ons​

Beyond antenna configurations, customers can independently select additional modules and software options according to their operational needs.
Each Scout unit can be customized with connectivity and data-service features tailored to the deployment scenario.

LTE Modem​

Adds integrated LTE connectivity, enabling real-time data transmission without Ethernet connection.
Ideal for remote deployments or temporary installations where wired internet is unavailable.
The LTE module can be added to any Scout configuration, regardless of antenna setup.

Yearly Cloud License​

Required to operate Scout in Cloud Mode, On-Premise Mode, or Sensor+ Mode.

  • Includes access to Dronetag Cloud, live visualization, data history, deduplication, and integrations.
  • Not required for Sensor Mode, where Scout is used for raw data collection and integration into your own system.
    The license can be activated independently of hardware configuration.

Coming Soon – Expansion Options​

Future versions of Scout will support optional modules such as ADS-B, ADS-L, FLARM and others, further extending detection capabilities beyond Remote ID to provide complete situational awareness across both crewed and uncrewed aviation.

💡 Need help choosing?

  • Baseline – ideal for standard airspace awareness.
  • Directional setups – increase range and precision for specific sectors.
  • LTE + Cloud License – unlock remote, real-time, and multi-sensor features for enterprise or security applications.
